37Trail Tech Voyager
The warning LED’s will turn on or flash when the
temperature reaches set points.
Warning LED Lights:
This menu contains items not needed for normal
use.
Utility Menu:
Utility > Status Screen:
Provides an overview of system variables.
Utility > Software Update:
Upgrades Voyager software. Visit
www.trailtech.net for the latest releases. After
downloading from Trail Tech, copy the file to the
MicroSD card, then select it with this function.
Utility > Service Menu:
Password protected features, including screen
dump and debug messages. Only available to
Trail Tech technicians.
The warning LEDs are disabled by default. Here
are some suggested values for common off-road
motorcycle applications:
Yellow LED on:
Red LED on:
Yellow LED flash:
Red LED flash:
90ºC (190ºF)
100ºC (210ºF)
110ºC (230ºF)
120ºC (250ºF)
