V1.2 09/01/15 UD0130 Page 55 of 63
6. TRAKA21 TECHNICAL DETAILS
6.1 SYSTEM SIZE
Please see below a list and diagram of the Traka21’s height, width and depth.
Height – 427.00mm
Width – 246.28mm
Depth – 90.40mm
6.2 SYSTEM WEIGHT
Traka21 with iFobs (without keys or optional battery) is 3.94Kg. Optional battery is an additional 0.63 Kg
6.3 POWER DETAILS
Traka21 uses a 15 ~ 24W AC-DC Single Output power supply. Please see the technical details below.
Input – 100-240VAC, 50-60Hz, 0.7A
Output – 15V 1.6A
Safety Standards – UL60950-1, CSA C22.2, TUV EN60950 -1, CCC GB4943 approved
