TRAKA21 KC-1-0156 - Battery Installation

V1.2 09/01/15 UD0130 Page 57 of 63
7.3 BATTERY INSTALLATION
To install the battery you will need to remove the top panel of the system.
1. Unscrew the cover plate using a 2mm Allen Key.
2. Remove the cover plate and screws.
