Trane BCHC - Basic Piping; Deluxe Piping; Piping Package Dimensions, In.; Piping Packages

BCXC-SVX01A-EN 15
Dimensions
and Weights
Installation
Piping Packages
AB
C
D
Two-Way,
1
/
2
” & 1” Deluxe Piping Package
Three-Way,
1
/
2
” & 1” Deluxe Piping Package
A
B
AB
C
D
E
F
Two-Way,
1
/
2
” & 1” Basic Piping Package
Three-Way,
1
/
2
” & 1” Basic Piping Package
AB
A
A
B
AB
A
B
E
F
B
Basic Piping
Deluxe Piping
Piping Package Dimensions, in.
Piping nominal actual
Package size size A B C D E F
2-way 0.50 0.625 12.025 2.650 12.625 5.650 na na
1.00 1.125 13.295 4.260 13.220 9.288 3.020 na
3-way 0.50 0.625 12.088 2.097 12.688 4.497 6.351 6.351
0.75 0.875 15.623 1.750 15.313 6.290 6.701 6.701
1.00 1.125 13.370 3.690 13.210 9.060 9.813 9.813
1.25 1.375 16.885 3.738 16.410 10.023 3.052 10.520
B
B
A
AB
A
E
Two-Way, 1
1
/
4
” Basic Piping Package
D
C
Two-Way 1
1
/
4
” Deluxe Piping Package
E
BA
AB
C
