44 BCXC-SVX01A-EN
Maintenance
Maintenance
Procedures
Table M-MP-2. BCHC/BCVC Fan, Filter, & Mixing Box General Data
Unit Size 12 18 24 36 54 72 90
nominal cfm 400 600 800 1200 1800 2400 3000
airflow
minimum cfm 250 375 500 750 1125 1500 1875
maximum cfm 500 675 1000 1600 2400 3000 4000
Fan Data
fan wheel dia., in. 9.5 x 4.5 9.5 x 4.5 9.5 x 4.5 9.5 x 4.5 9.5 x 4.5 9.5 x 4.5 9.5 x 4.5
max rpm 2300 2300 1800 1800 1500 1500 1500
motor hp 0.33-1.0 0.33-1.0 0.33-1.0 0.33-1.5 0.33-2.0 0.33-3.0 0.33-3.0
Unit Flat Filter
qty. - size, in. 1 - 12x 24 1 - 12x 24 1 - 16x 25 2 - 16x 20 1 - 20x 20 3 - 16x 25 2 - 20x 25
1 - 20x 25 1 - 16x 25
area, sq. ft. 2.000 2.000 2.778 4.444 5.556 6.250 8.333
velocity, ft./min. 200 300 288 270 324 384 360
Angle Filter
qty. - size, in. 2 - 12x24 2 - 12x24 2 - 12x24 2 - 20x20 4 - 16x20 4- 16x20 4- 20x20
area, sq. ft. 4.000 4.000 4.000 5.556 8.889 8.889 11.111
velocity, ft./min. 100 150 200 216 203 270 270
Bottom/Top Access Filter Box
qty. - size, in. 1 - 12x20 1 - 12x24 1 - 16x25 1 - 16x20 1 - 16x20 1 - 20x25 2 - 16x25
1 - 16x16 1 - 20x20 1 - 20x20 1 - 14x25
area, sq. ft. 1.7 2.0 2.8 4.0 5.0 6.3 8.0
velocity, ft./min. 240 300 288 300 360 384 375
Mixing Box
damper opening width, in. 15.5 19.5 19.5 31.5 31.5 31.5 31.5
damper opening height, in. 7 7 7 7 12.75 12.75 12.75
area, sq. ft. 0.753 0.948 0.948 1.531 2.789 2.789 2.789
velocity, ft./min. 531 633 844 784 645 861 1076
Note: Minimum airflow limits apply to units with hot water or electric heat only. There is no minimumairflow limit on cooling on units. Maximum airflow limits are to help prevent
moisture carryover.
Table M-MP-3. BCHC/BCVC Piping Package
Waterflow Limits
Piping
Size gpm
1
/
2
” 8.6
3
/
4
” 19.3
1” 34.3
1
1
/
4
” 53.5
Note: Trane recommends these maximum gpms to help
prevent erosion and/or noise problems. However lower
gpms may be necessary, depending on the
systemdesign, to avoid exceeding close-off pressure
limit of the control valve.
