40 BCXC-SVX01A-EN
Operation
Sequence of
Operation
Table O-SO-12. Binary Output Configuration
Binary Output
Pin Connection Configuration ZN010 ZN510 ZN520
J1-1 Fan high ✓✓✓
J1-2 N/A ✓✓✓
J1-3 Fan low ✓
J1-4 (Key) ✓
Fan low ✓✓
J1-5 Main valve – open, or ✓✓✓
2 pos. valve, (Note 1)
J1-6 Aux. valve/elec. ht. ✓✓
Aux. valve – close (Note 1) ✓
J1-7 2-pos. damper ✓✓
J1-9 Heat valve – open, or ✓
2 pos. valve, or
first stage elec. ht. (Note 1)
J1-10 Heat valve – close or ✓
sec. stage elec. ht.(Note 1)
J1-11 Fresh air damper - open ✓
J1-12 Fresh air damper - close ✓
TB4-1 Generic / baseboard heat output ✓
TB4-2 24 VAC ✓
Note:
1. 2-pipe hydronic heat/cool changeover units use terminals J1-5 and J1-6 to control the primary valve for both heating and
cooling. Units configured and applied as 2-pipe hydronic heat/cool changeover with electric heat, use terminals J1-5 and
J1-6 to control the primary valve (for both cooling and heating), and terminals J1-9 and J1-10 for the electric heat stage.
For those 2-pipe changeover units, electric heat will not energize while the hydronic supply is hot (5 or more degrees
above the space temperature). In a four-pipe application, pin J1-5 is for cooling and pin J1-6 for heating.
2. If no valves are ordered with the unit, the factory default for Tracer ZN010 and ZN510 controllers are:
main valve configured as normally closed
aux. valve configured as normally open
3. If the fresh air damper option is not ordered on the unit, 2-pos. damper is configured as none.
4. Pin J1-2 can be configured for an exhaust fan with the use of Rover Software.Factory default is none.
Table O-SO-11. Analog Inputs
Analog Input Terminal Function Range ZN010 ZN510 ZN520
Zone TB3-1 Space temperature input 5° to 122°F (-15° to 50°C) ✓✓✓
Ground TB3-2 Analog ground NA ✓✓✓
Set TB3-3 Setpoint input 40° to 115°F (4.4° to 46.1°C) ✓✓✓
Fan TB3-4 Fan switch input 4821 to 4919 W (Off) ✓✓✓
2297 to 2342 W (Auto)
10593 to 10807 W (Low)
15137 to 16463 W (High)
Ground TB3-6 Analog ground NA ✓✓✓
Analog Input 1 J3-1 Entering water temperature -40° to 212°F (-40° to 100°C) ✓✓✓
J3-2 Analog ground NA
Analog Input 2 J3-3 Discharge air temperature -40° to 212°F (-40° to 100°C) ✓✓✓
J3-4 Analog ground NA
Analog Input 3 J3-5 Fresh air temp/generic temp -40° to 212°F (-40° to 100°C) ✓
J3-6 Analog ground NA
Analog Input 4 J3-7 Universal Input 0 – 100% ✓
Generic 4-20 ma 0 – 100%
Humidity 0 – 2000ppm
CO
2
J3-8 Analog ground NA ✓
Ground J3-9 Analog ground NA ✓
Notes:
1) The zone sensor, entering water temperature sensor, discharge air sensor, and the outside air temperature sensor are 10KW thermistors.
2) Zone sensor: Wall mounted sensors include a thermistor soldered to the sensor’s circuit board.
3) Changeover units include an entering water temperature sensor.
