50 BCXC-SVX01A-EN
Table M-T-4. Tracer ZN010 and ZN510 Test Sequence for 1–Heat /1–Cool Configurations
Steps Fan Cool Output (1) Heat Output Damper
J1-1, J1-3 J1- J1- J1-
1. Off Off Off Off Closed
2. Fan High High Off Off Closed
3. Exhaust Fan Note 5 Off Off Closed
4. Fan Low Off Off Closed
5. Cool High On Off Closed
6. Heat High Off On Closed
7. Two position High Off Off Open
Damper
(3)
8.
Exit Note 2
Notes:
1. At the beginning of step 2, the controller attempts to clear all diagnostics.
2. For all 1-heat/1-cool applications including 2-pipe changeover, the cooling and heat test stage energize. This occurs even
though during normal 2-pipe changeover operation binary output controls the unit valve for both cooling and heating.
3. After the fresh air damper step, the test sequence performs the exit step.This initiates a reset and attempts to return the
controller to normal operation.
4.
The 2-position damper energizes during this step if the controller is configured for a 2-position damper.
5. ZN010 and ZN510 has a binary output default as “none” on J1- X from the factory. If the unit has a 2-speed fan, step 3 will
energize the low fan speed. If the unit has a single speed fan, step 3 will continue to energize the high fan speed. This
binary output can be reconfigured as an exhaust fan, with the use of Rover software
Table M-T-5. Tracer ZN520 Test Sequence
Main Electric heat Fresh air Generic/
Fan valve or aux. valve damperbaseboard heat
Step J1-1 J1-2 J1-3 J1-5 J1-6 J1-9 J1-10 J1-11 J1-12 TB4-1
1: Off
1
Off Off Off Off On Off aux: on Off On Off
EH: off
2: Fan High
2
High Off Off Off Off Off Off Off Off OfF
3: (Note 3) Off Note3 Off Off Off Off Off Off Off Off
4: Fan low Off Off Low Off Off Off Off Off Off Off
5: Main open High Off Off On Off Off Off Off Off Off
6: Main close, High Off Off Off On On Off Off Off Off
EH1 on
7: Aux open, High Exh Off Off Off On Off Off Off Off
EH1 on Note 4
8: Aux close, High Off Off Off Off Off On On Off Off
damper open EH1 off, EH2 on,
9: Damper close High Off Off Off Off Off Off Off On Off
10: Generic/ High Off Off Off Off Off Off Off Off On
baseboard
heat energized
11: Exit
6
Exit
1
Note 1. Upon entering manual output test mode, the controller turns off all fan and electric heat outputs and drives.
Note 2. At the beginning of step 2, the controller attempts to clear all diagnostics.
Note 3. The low fan speed output energizes at step 3. If the unit is configured for a 1 speed fan, the fan remains on high
speed at step 3.
Note 4. If the unit is configured for a 1 or 2 speed fan, and BOP2 is configured for an exhaust fan, the exhaust fan output
energizes on step 7. The exhaust fan output is shared with medium speed.
Note 5. After step 10, the test sequence performs an exit. This initiates a reset and attempts to return the controller to
normal operation.
The green LED is turned off when the
Test button is pressed. To begin the
manual output test mode, press and hold
the Test button (turning off the green
LED) for at least two seconds. The green
LED will begin to blink, indicating the
controller is in test mode.
Maintenance
Troubleshooting
