30 BCXC-SVX01A-EN
Operation
General
Information
Table O-GI-1. Tracer Controller Input/Output Summary
Tracer Controller
ZN010 ZN510 ZN520
Binary Outputs
2-speed fan
aaa
2-position hydronic valve aaa
2-position mixing box damper aa
1-stage electric heat aaa
modulating mixed air damper a
modulating hydronic valve a
2-stage electric heat a
reheat (hydronic) a
generic aaa
Binary Inputs
condensate overflow detection
aaa
low temperature detection aaa
occupancy aaa
generic input aaa
Analog Inputs
zone temperature
aaa
setpoint aaa
fan mode: auto, high, low aaa
entering water aaa
discharge air aaa
outside air a
generic a
Note: The generic input and output are for use with a Tracer Summit system only.
Table O-GI-2. Tracer Controller Function Summary
Tracer Controller
ZN010 ZN510 ZN520
Control Functions
entering water temp. sampling (purge)
aa a
timed override aa a
auto changeover aa a
fan cycling aa
warmup aa a
pre-cool aa a
data sharing (master/slave) aa
random start aa a
dehumidification a
staged capacity (2-stage electric supplementary) a
DX cooling a
Other Functions
manual test
aa a
filter maintenance timer aa a
setpoint limits aa a
