Trane BCHC - Motor Electrical Data

22 BCXC-SVX01A-EN
Electrical
RequirementsInstallation
Table I-ER-3. Motor Electrical Data
Voltage voltage range rpm rated hp lbs. fla lra
115/60/1 104-126 1750
1
/
3
18 5.8 22.8
1
/
2
21 7.2 30.4
3
/
4
29 12.0 58.4
1.0 29 12.8 58.4
two-speed
115/60/1 104-126 1750/1160
3
/
4
40 8.9/6.1 42.0
1.0 41 11.5/8.1 58.2
208-230/60/1 187-253 1750
1
/
3
18 3.1 11.4
1
/
2
21 3.6 15.2
`
3
/
4
29 6.0 29.2
1.0 29 6.4 29.2
277/60/1 249-305 1750
1
/
3
15.5 2.5 12.1
1
/
2
21.5 3.6 19.3
3
/
4
25 4.3 25.3
`
1.0 29 5.6 32.6
208/60/3 187-229 1750
1
/
2
22 2.3 11.4
3
/
4
26 2.9 15.9
1.0 28 3.5 20.2
`
1.5 29 4.8 30.0
2.0 34 6.2 38.5
3.0 49 8.6 55.1
230/60/3 207-253 1750
1
/
2
22 2.4 12.8
3
/
4
26 3.0 18.6
1.0 28 3.6 23.0
`
1.5 29 4.8 33.4
2.0 34 6.2 43.6
3.0 49 8.6 62.0
460/60/3 414-506 1750
1
/
2
22 1.2 6.4
3
/
4
26 1.5 9.3
1.0 28 1.8 11.5
`
1.5 29 2.4 16.7
2.0 34 3.1 21.8
3.0 49 4.3 31.0
575/60/3 518-632 1750
3
/
4
20.5 1.1 7.5
1.0 22.5 1.4 9.0
1.5 31 1.9 13.3
`
2.0 36 2.5 17.9
3.0 49 3.3 23.7
220/50/1 198-242 1450
1
/
3
20.5 3.0 15.6
1
/
2
25 3.6 20.5
`
3
/
4
29 5.2 25.6
1.0 38 9.3 52.2
240/50/1 216-264 1450
1
/
3
20.5 3.3 17.1
1
/
2
25 4.0 22.7
`
3
/
4
29 5.5 39.1
1.0 38 10.6 57.8
190/50/3 171-209 1450
1
/
3
22 1.1 5.6
380/50/3 342-418
1
/
2
26 1.4 7.8
`
3
/
4
28 1.7 9.8
1.0 29 2.1 14.6
1.5 34 2.8 18.7
2.0 49 3.6 27.2
415/50/3 374-456 1450
1
/
3
22 1.2 6.8
1
/
2
26 1.5 9.4
`
3
/
4
28 1.9 11.0
1.0 29 2.5 17.4
1.5 34 3.1 22.6
2.0 49 3.6 32.3
