114 CG-SVX17D-EN
Controls Interface
Local Time of Day Schedule Subscreen (see below)
External/BAS Subscreen (see below)
Chilled Water Reset Subscreen (see below)
Table 43. External/BAS Feature Settings (subscreen of Feature Settings)
Description
Resolution or (Enumerations),
Default Units
Ext Chilled Setpt: (Enable, Disable), Disable Enum
Ext Demand Limit Setpoint: (Enable, Disable), Disable Enum
Max Capacity Debounce Time: 30 seconds Seconds (MM:SS)
Limit Annunc Debounce Time: 30 seconds Seconds (MM:SS)
LCI-C Diag Encoding: (Text, Code) Text Enum
LCI-C Diag Language:
(English, Selection 2, Selection 3)
English (0)
Enum
Table 44. Chilled Water Reset Feature Settings (subscreen of Feature Settings)
Description
Resolution or (Enumerations),
Default Units
Chilled Water Reset:
(Const Return, Outdoor, Return, Disable),
Disable
Enum
Return Reset Ratio: XXX Percent
Return Start Reset: XXX.X Temperature
Return Maximum Reset: XXX.X Temperature
Outdoor Reset Ratio: XXX Percent
Outdoor Start Reset: XXX.X Temperature
Outdoor Maximum Reset: XXX.X Temperature
Table 45. Control Settings
Description
Resolution or (Enumerations),
Default Units
Cooling Design Delta Temp: XXX.X Delta Temperature
Heating Design Delta Temp: XXX.X Delta Temperature
Differential to Start: XXX.X Delta Temperature
Differential to Stop: XXX.X Delta Temperature
Staging Deadband Adjustment: XXX.X Delta Temperature
Capacity Control Softload Time: 120 seconds Seconds (MM:SS)
Circuit Staging Option:
(Bal Starts/Hrs, Circuit 1 Lead, Circuit 2
Lead), Bal Starts/Hrs
Enum
Compressor Staging Option: (Fixed, Bal Starts/Hrs) Enum
Leaving Water Temp Cutout: XX.X Temperature
Low Refrigerant Temp Cutout: XX.X Temperature
Table 42. Feature Settings
Description
Resolution or (Enumerations),
Default Units
