94 CG-SVX17D-EN
CGAM Operating Principles
Pump Package Components - Optional
Figure 65. Pump package components — slant 20-35 ton — view 1
Figure 66. Pump package components — slant 20-35 ton — view 2
Pump
Junction box
Relief valve
Flexible hose
Handle
Blow down valve
Thermostat
Butterfly Valve
Strainer
Pressure port
Gauge
Pressure port
Immersion heater
Manual air bleed
Expansion tank
Victaulic coupling
Drain valve
Flow switch
Temperature sensor
Junction box
T
hermostat
Pressure port
Immersion heaters
Temperature sensor
Thermostat
Butterfly valve
