Trane CGAM - Weights

CG-SVX17D-EN 39
Unit Dimensions/Weights
Weights
Table 8. Weights - 60 Hz - no options
Tons
Shipping Weight Operating Weight
poundskilogramspoundskilograms
20
1968 892 1989 902
26
2020 916 2047 929
30
2562 1162 2588 1174
35
2592 1176 2627 1192
40
3508 1591 3537 1604
52
3589 1628 3629 1646
60
4639 2104 4687 2126
70
4702 2133 4770 2557
80
5419 2458 5483 2487
90
5677 2575 5757 2611
100
6329 2871 6420 2912
110
6357 2883 6457 2929
120
6357 2883 6457 2929
130
7511 3407 7618 3455
1. Weights based on aluminum fins.
2. Weights do not include louvers, partial heat recovery, etc.
3. All weights ±5%.
Table 9. Weights - 60 Hz - with options
Tons
With Pump With Pump and Buffer Tank
Shipping Weight Operating Weight Shipping Weight Operating Weight
pounds kilograms pounds kilograms pounds kilograms pounds kilograms
20
2560 1161 2633 1194 2974 1349 4218 1913
26
2612 1185 2691 1221 3027 1373 4276 1940
30
3246 1472 3325 1508 3660 1660 4910 2227
35
3276 1486 3364 1526 3690 1674 4948 2244
40
4126 1872 4208 1909 4540 2059 5792 2627
52
4207 1908 4300 1950 4621 2096 5885 2669
60
5383 2442 5484 2488 5797 2630 7069 3206
70
5446 2470 5566 2525 5860 2658 7151 3244
80
6356 2883 6510 2953 6770 3071 8187 3714
90
6614 3000 6785 3078 7029 3188 8462 3838
100
7266 3296 7447 3378 7680 3484 9483 4301
110
7294 3309 7484 3440 7709 3497 9520 4318
120
7646 3468 4836 3554 8061 3656 9872 4478
130
8849 4014 9046 4103 9263 4202 11082 5027
1. Weights based on aluminum fins.
2. Weights do not include louvers, partial heat recovery, etc.
3. All weights ±5%.
