Trane CGAM User Manual

CG-SVX17D-EN 61
Installation - Mechanical
Performance Adjustment Factors
Concentration and type of glycol used will affect unit performance. If operating conditions,
including concentration of freeze inhibitor, have changed since the unit was ordered, contact sales
representative to rerun selection. See Figure 46, p. 61 through Figure 51, p. 63 for approximate
adjustment factors.
Figure 46. Ethylene glycol performance factor - compressor power adjustment
0.994
0.9945
0.995
0.9955
0.996
0.9965
0.997
0.9975
0.998
0.9985
0.999
0 5 10 15 20 25 30 35 40 45
ADJUSTMENT FACTOR
% ETHYLENE GLYCOL BY WEIGHT
60 Hz
50 Hz
Figure 47. Propylene glycol performance factor - compressor power adjustment
0.988
0.989
0.99
0.991
0.992
0.993
0.994
0.995
0.996
0.997
0.998
0.999
0 5 10 15 20 25 30 35 40 45 50
ADJUSTMENT FACTOR
% PROPYLENE GLYCOL BY WEIGHT
60 Hz
50 Hz
