60 CG-SVX17D-EN
Installation - Mechanical
25 11.4 1.4 14.4 21.4 18.9 18.1 25 14.8 4.8 17.8 21.4 18.9 18.1
26 10.2 0.2 13.2 20.2 17.7 16.9 26 13.8 3.8 16.8 20.2 17.7 16.9
27 9.0 -1.0 12.0 19.0 16.5 15.7 27 12.7 2.7 15.7 19.0 16.5 15.7
28 7.7 -2.3 10.7 17.7 15.2 14.4 28 11.6 1.6 14.6 17.7 15.2 14.4
29 6.4 -3.6 9.4 16.4 13.9 13.1 29 10.5 0.5 13.5 16.4 13.9 13.1
30 5.1 -4.9 8.1 15.1 12.6 11.8 30 9.3 -0.7 12.3 15.1 12.6 11.8
31 3.7 -6.3 6.7 13.7 11.2 10.4 31 8.1 -1.9 11.1 13.7 11.2 10.4
32 2.3 -7.7 5.3 12.3 10.4 10.4 32 6.8 -3.2 9.8 12.3 10.4 10.4
33 0.8 -9.2 3.8 10.8 10.4 10.4 33 5.5 -4.5 8.5 10.8 10.4 10.4
34 -0.7 -10.7 2.3 10.4 10.4 10.4 34 4.1 -5.9 7.1 10.4 10.4 10.4
35 -2.3 -12.3 0.7 10.4 10.4 10.4 35 2.7 -7.3 5.7 10.4 10.4 10.4
36 -3.9 -13.9 -0.9 10.4 10.4 10.4 36 1.3 -8.7 4.3 10.4 10.4 10.4
37 -5.6 -15.6 -2.6 10.4 10.4 10.4 37 -0.3 -10.3 2.7 10.4 10.4 10.4
38 -7.3 -17.3 -4.3 10.4 10.4 10.4 38 -1.8 -11.8 1.2 10.4 10.4 10.4
39 -9.0 -19.0 -5.0 10.4 10.4 10.4 39 -3.5 -13.5 -0.5 10.4 10.4 10.4
40 -10.8 -19.0 -5.0 10.4 10.4 10.4 40 -5.2 -15.2 -2.2 10.4 10.4 10.4
41 -12.7 -19.0 -5.0 10.4 10.4 10.4 41 -6.9 -16.9 -3.9 10.4 10.4 10.4
42 -14.6 -19.0 -5.0 10.4 10.4 10.4 42 -8.8 -18.8 -5.0 10.4 10.4 10.4
43 -16.6 -19.0 -5.0 10.4 10.4 10.4 43 -10.7 -19.0 -5.0 10.4 10.4 10.4
44 -18.6 -19.0 -5.0 10.4 10.4 10.4 44 -12.6 -19.0 -5.0 10.4 10.4 10.4
45 -20.7 -19.0 -5.0 10.4 10.4 10.4 45 -14.6 -19.0 -5.0 10.4 10.4 10.4
46 -22.9 -19.0 -5.0 10.4 10.4 10.4 46 -16.7 -19.0 -5.0 10.4 10.4 10.4
47 -25.1 -19.0 -5.0 10.4 10.4 10.4 47 -18.9 -19.0 -5.0 10.4 10.4 10.4
48 -27.3 -19.0 -5.0 10.4 10.4 10.4 48 -21.1 -19.0 -5.0 10.4 10.4 10.4
49 -29.7 -19.0 -5.0 10.4 10.4 10.4 49 -23.4 -19.0 -5.0 10.4 10.4 10.4
50 -32.1 -19.0 -5.0 10.4 10.4 10.4 50 -25.8 -19.0 -5.0 10.4 10.4 10.4
51 -34.5 -19.0 -5.0 10.4 10.4 10.4 51 -28.3 -19.0 -5.0 10.4 10.4 10.4
52 -37.1 -19.0 -5.0 10.4 10.4 10.4 52 -30.8 -19.0 -5.0 10.4 10.4 10.4
53 -39.7 -19.0 -5.0 10.4 10.4 10.4 53 -33.4 -19.0 -5.0 10.4 10.4 10.4
54 -42.3 -19.0 -5.0 10.4 10.4 10.4 54 -36.1 -19.0 -5.0 10.4 10.4 10.4
55 -45.0 -19.0 -5.0 10.4 10.4 10.4 55 -38.9 -19.0 -5.0 10.4 10.4 10.4
Table 23. Low Evap Refrigerant Temp Cutout and Low Water Temp Cutout
ETHYLENE GLYCOL PROPYLENE GLYCOL
%
Glycol
Solution
Freeze
Point [F]
Low
Refrig
Temp
Cutout
[F]
Low
Water
Temp
Cutout
[F]
Min Chilled Water Set
Point [F]
%
Glycol
Solution
Freeze
Point [F]
Low
Refrig
Temp
Cutout
[F]
Low
Water
Temp
Cutout
[F]
Min Chilled Water Set
Point [F]
Number of
compressors
Number of
compressors
246 246
