Trane CGAM User Manual

CG-SVX17D-EN 97
CGAM Operating Principles
Buffer Tank Components - Optional
Figure 71. Pump package components — W 80-130 ton — view 2
Pressure port
Temperature sensor
Flow switch
Butterfly valve
Victaulic coupling
Victaulic coupling
Manual air bleed
Pressure port
Immersion heater
Drain valve
Temperature sensor
Immersion heater
Figure 72. Buffer tank components — slant 20-35 ton & V 40-70 ton
Pressure port
Immersion heater
Victaulic coupling
Auto air bleed
Auto air bleed
Thermostat
Junction box
Victaulic coupling
