Trane CGAM - Local Time of Day Schedule Screen

CG-SVX17D-EN 11 5
Controls Interface
Local Time of Day Schedule Screen
To access the Local Time of Day Schedule Screen this option must be installed in TechView. This
option will then be shown under the Feature Settings screen.
Evap Flow Overdue Wait Time: 30 seconds Seconds (MM:SS)
Disch Press Limit Setpt: 85% Percent
Disch Press Limit Unload Setpt: 97% Percent
Table 46. System Manual Control Settings
Description
Resolution or
(Enumerations), Default Units Monitor Value
Evap Water Pump (Auto, On), Auto Enum
1) Evap Flow status
2) Override Time Remaining
Clear Restart Inhibit Timer (Clear Timer)
1) Restart Inhibit Time (composite
value)
Capacity Control (Auto, Manual) Auto Enum
Binding Special Special None
Table 47. Circuit Manual Control Settings
Description Resolution or (Enumerations), Default Units Monitor Value
Front Panel Ckt Lockout (Not Locked Out, Locked Out), Not Locked Out Enum
Cprsr A Lockout (Not Locked Out, Locked Out), Not Locked Out Enum
Cprsr B Lockout (Not Locked Out, Locked Out), Not Locked Out Enum
Cprsr C Lockout (Not Locked Out, Locked Out), Not Locked Out Enum
Manual EXV Control: (Auto, Manual), Auto Enum
Manual EXV Position Cmd: XXX Percent
EXV Status
Suction Pressure
Cooling EXV Manual Ctrl: (Auto, Manual), Auto Enum
Cooling EXV Manual
Position Cmd:
XXX Percent
EXV Status
Suction Pressure
Cprsr A Pumpdown
Status: (Avail, Not Avail, Pumpdown)
Override Subscreen command buttons:
(Abort, Pumpdown) - button is either grayed out or not
shown if not available
Enum Suction Pressure
Cprsr B Pumpdown
Status: (Avail, Not Avail, Pumpdown)
Override Subscreen command buttons:
(Abort, Pumpdown) - button is either grayed out or not
shown if not available
Enum Suction Pressure
Cprsr C Pumpdown
Status: (Avail, Not Avail, Pumpdown)
Override Subscreen command buttons:
(Abort, Pumpdown) - button is either grayed out or not
shown if not available
Enum Suction Pressure
Table 45. Control Settings
Description
Resolution or (Enumerations),
Default Units
