Unit Shutdown
Normal Shutdown to Stopped
The Normal Shutdown diagram shows the Transition from Running through a Normal
(friendly) Shutdown. The Dashed lines on the top attempt to show the final mode if you
enter the stop via various inputs.
Figure 97. Normal Shutdown
