CGAM Operating Principles
Figure 67. Pump package components — V 40-70 ton — view 1
Figure 68. Pump package components — V 40-70 ton — view 2
Immersion Heater
Handle
Gauge pressure port
Flexible hose
Blow down valve
Pressure port
Drain Valve
Pump
Temperature sensor
Junction box
Thermostat
Relief valve
Expansion tank
Victaulic coupling
Manual air bleed
Pressure port
Drain valve
Temperature sensor
Strainer
Butterfly valve
Victaulic coupling
Immersion Heaters
Butterfly valve/balance valve
