Trane CGAM User Manual

CG-SVX17D-EN 123
Controls Interface
Table 49. Report name: System Evaporator
Description Resolution Units
Evap Entering Water Temp: + or - XXX.X Temperature
Evap Leaving Water Temp: + or - XXX.X Temperature
Evap Pump Inverter 1 Run Cmd: On, Off Enumeration
Evap Pump 1 Command: On, Off Enumeration
Evap Pump 2 Command: On, Off Enumeration
Evap Water Flow Switch Status: Flow, No Flow Enumeration
Table 50. Report name: Circuit Evaporator
Description Resolution Units
Suction Pressure XXX.X Pressure
Suction Saturated Rfgt Temp: + or - XXX.X Temperature
Suction Temperature: + or - XXX.X Temperature
Evap Approach Temp: + or - XXX.X Temperature
EXV Position Status: XXX.X Percent
Heating EXV Position Status: XXX.X Percent
Table 51. Report name: System Condenser
Description Resolution Units
Outdoor Air Temperature: + or - XXX.X Temperature
Heat Rcvy Entering Water Temp: + or - XXX.X Temperature
Heat Rcvy Leaving Water Temp: + or - XXX.X Temperature
Table 52. Report name: Circuit Condenser
Description Resolution Units
Discharge Pressure: XXX.X Pressure
Discharge Saturated Rfgt Temp: + or - XXX.X Temperature
Discharge Temperature: + or - XXX.X Temperature
Cond Approach Temp: + or - XXX.X Temperature
Current Air Flow: XXX.X Percent
Table 53. Report name: System Compressor
Description Resolution Units
Chiller Running Time: XXXX:XX hr:min
Table 54. Report name: Circuit Compressor
Description Resolution Units
Compressor A Starts: XXXX Integer
Compressor A Running Time: XXXX:XX hr:min
