Trane CGAM - Page 20

20 CG-SVX17D-EN
General Data
Table 5. General Data – 60 Hz – SI
Size 20 26 30 35 40 52 60 70 80 90 100 110 120
Compressor
Number#22224444444 4 4
Tonnage/circuit¹ 10+10 13+13 15+15 15+20 10+10 13+13 15+15 15+20 20+20 20+25 25+25 25+30 30+30
Evaporator
Water storage (l) 5.3 8.3 8.3 12.1 9.1 15.5 18.9 28.4 26.5 34.1 39.0 43.5 43.5
Min. flow² (l/s) 1.5 1.9 2.1 2.5 2.9 3.7 4.2 5.0 5.8 6.5 7.3 7.9 8.6
Max. flow² (l/s) 4.4 5.6 6.3 7.4 8.6 11.1 12.7 15.1 17.4 19.4 21.9 23.7 25.7
Water connection (mm) 50.8 63.5 63.5 63.5 76.2 76.2 76.2 76.2 101.6 101.6 101.6 101.6 101.6
Condenser
Quantity of coils#11112222444 4 4
Coil length (mm) 2311 2311 3226 3226 2311 2311 3226 3226 3073 3073 3658 3658 3658
Coil height (mm) 1727 1727 1727 1727 1727 1727 1727 1727 1067 1067 1067 1067 1067
Number of rows#22222222333 3 3
Fins per foot (fpf) 192 192 192 192 192 192 192 192 192 192 192 192 192
Fan
Quantity/circuit¹#22332233234 4 4
Diameter (mm) 732 732 732 732 732 732 732 732 732 732 732 732 732
Airflow per fan
(m³/
h)
15993 16005 15577 15585 15993 16005 15577 15585 16090 16093 15451 15454 15458
Power per motor (kW) 1.2 1.2 1.2 1.2 1.2 1.2 1.2 1.2 1.2 1.2 1.2 1.2 1.2
Motor RPM (rpm) 840 840 840 840 840 840 840 840 840 840 840 840 840
Tip speed (m/s) 32 32 32 32 32 32 32 32 32 32 32 32 32
General Unit
Refrig circuits#11112222222 2 2
Capacity steps % 50-100 50-100 50-100 43-100
25-50-
75-100
25-50-
75-100
25-50-
75-100
21-43-
71-100
25-50-
75-100
22-44-
72-100
25-50-
75-100
23-45-
73-100
25-50-
75-100
Refrig charge/
circuit¹
(kg) 15.4 15.4 21.8 21.8 14.5 14.5 21.8 21.8 33.6 33.6 40.9 39.0 39.0
Oil charge /circuit¹ (l) 6.4 6.4 13.2 14.0 6.4 6.4 13.2 14.0 14.4 15.1 15.5 16.3 16.7
Min ambient
Wide ambient (°C) -18 -18 -18 -18 -18 -18 -18 -18 -18 -18 -18 -18 -18
1. Data shown for circuit one only. The second circuit always matches.
2. Flow limits are for water only.
