26 CG-SVX17D-EN
Unit Dimensions/Weights
Figure 11. CGAM 30 and 35 ton - no options
Figure 12. CGAM 30 and 35 ton - service clearances and mounting locations
connection
Wire
Control
Fan
Compressor
Chilled water
inlet
Chilled water
outlet
84.7 in
(2151 mm)
50.4 in
(1279 mm)
(541 mm)21.3 in
128.4 in (3263 mm)
149.8 in
(3804 mm)
20.3 in
(246 mm)
9.7 in
(429 mm)
panel
16.9 in
Water connections are 1.6 in (40 mm)
from unit end.
The number of fans shown does not represent
the number of fans installed.
(516 mm)
Mounting Locations
Door
Service Clearance
Hole dia
Distance from edge to
(600 mm)
39.4 in
(1000 mm)
(556 mm)
23.6 in
132.2 in (3358 mm)
47.2 in (1200 mm)
47.2 in
swing
21.9 in
0.56 in (15 mm)
middle of mounting hole
(1199 mm)
1.5 in (38 mm)
31.5 in
(800 mm)
Control
panel side
Total of four mounting locations.More clearance may be needed for airflow
depending on the installation.
The number of fans shown does not represent
the number of fans installed.
Chilled water
connection side
