Trane CGAM - Page 263

CG-SVX17D-EN 263
Unit Wiring
C
TRANE
REPLACEMENT FUSE TABLE
FUSE VOLTAGE Hz CLASS AMPS NOTES
1F1 ALL ALL CC 10
1F2 ALL ALL CC 10
1F3 ALL ALL CC 10
1F4 ALL ALL CC 10
200 60 CC 10
230 60 CC 8
380 60 CC 5
400 50 CC 5
460 60 CC 5
575 60 CC 4
200 60 CC 10
230 60 CC 8
380 60 CC 5
400 50 CC 5
460 60 CC 5
575 60 CC 4
200 60 CC 10
230 60 CC 8
380 60 CC 5
400 50 CC 5
460 60 CC 5
575 60 CC 4
1F11 ALL ALL CC 10
FUSE, CONTROL POWER TRANSFORMER,
SECONDARY, 115V
1F12 - 1F13 ALL ALL CC 6
FUSE, CONTROL POWER TRANSFORMER,
SECONDARY, 24V
200-460 ALL CC 30
575 60 CC 6
1F38 - 1F40
1F44 - 1F46
ALL ALL CC 30
FAST ACTING FUSE,
ATM-R-30
1F38 - 1F40
1F41 - 1F43
ALL ALL CC 30
FAST ACTING FUSE,
USED ONLY ON W UNITS
FACTORY PROVIDED PUMP INVERTER FUSE
200,230 60 J 30 3.7Kw VSD
460,575 60 J 25 5.5 Kw VSD
200,230 J 60
460,575 CC 30
06032
,002
04575,064
1F32,
1F33,
1F34
60
60 J 11Kw VSD
7.5Kw VSD
1F14 - 1F16
1F17 - 1F19
FUSE, INVERTER, FAN
(FAST ACTING EXCEPT 575V)
FUSE, COMPRESSOR CRANKCASE HEATER,
CIRCUIT 1
FUSE, COMPRESSOR CRANKCASE HEATER,
CIRCUIT 2
FUSE, CONTROL POWER TRANSFORMER,
PRIMARY
THIRD PHASE, PHASE PROTECTION
MONITOR
DUAL POINT, POWER SECOND PHASE,
PHASE PROTECTION MONITOR
1F8,
1F9,
1F10
1F7
1F5,
1F6
Field Wiring Diagram - Notes
