50 CG-SVX17D-EN
Installation - Mechanical
Table 17. Point weights (lbs) - 60 Hz - with pump package
Isolator location
Without partial heat recovery With partial heat recovery
Size1234567812345678
20 ton
734659668593----736674673611----
26 ton
755670688604----757686694623----
30 ton
997750908661----1004774910679----
35 ton
1006754926674----1013778928693----
40 ton
118910711028945----107711681189896----
52 ton
110012081148879----108712061213933----
60 ton
1262 943 811 871 752 811 - - 1246 930 833 891 800 858 - -
70 ton
1154 1095 833 792 855 814 - - 1226 950 835 925 813 903 - -
80 ton
1487 1533 904 937 802 834 - - 1663 1553 809 1081 820 768 - -
90 ton
1635 1548 818 1110 847 805 - - 1614 1689 1064 1116 726 762 - -
100 ton
1258 1653 1279 1148 910 1169 - - 1344 1765 1311 1171 896 1139 - -
110 ton
1270 1680 1289 1165 916 1183 - - 1356 1792 1322 1187 902 1154 - -
120 ton
122117881224122112261224- - 131319041260124512081194- -
130 ton
903 1253883 1225121811811194115810531208106512201084123910941249
Table 18. Point weights (lbs) - 60 Hz - with pump package and buffer tank options
Isolator location
Without partial heat recovery With partial heat recovery
Size1234567812345678
20 ton
486 461 1702 1592 - - - - 492 472 1703 1614 - - - -
26 ton
640 338 1589 1736 - - - - 649 348 1588 1762 - - - -
30 ton
735 594 1935 1639 - - - - 745 614 1934 1660 - - - -
35 ton
743 598 1954 1651 - - - - 753 619 1953 1673 - - - -
40 ton
887 819 2128 1987 - - - - 879 812 2184 2043 - - - -
52 ton
904 849 2141 2027 - - - - 896 842 2201 2086 - - - -
60 ton
807 761 1145 1080 1670 1574 - - 796 750 1157 1092 1722 1626 - -
70 ton
803 770 1149 1102 1687 1618 - - 792 759 1162 1114 1741 1671 - -
80 ton
1941 2009 1284 1330 878 910 - - 2043 2111 1299 1345 860 892 - -
90 ton
2014 2106 1311 1374 885 929 - - 1974 2411 1369 1229 971 873 - -
100 ton
1817 2012 1708 1903 1092 1225 - - 1764 2354 1759 1721 1196 1170 - -
110 ton
1830 2036 1718 1924 1097 1237 - - 1776 2380 1770 1740 1203 1182 - -
120 ton
1812 2022 1804 2013 1224 1367 - - 1765 2371 1858 1832 1329 1311 - -
130 ton
1373 1249 1355 1231 1327 1765 1313 1743 1445 1322 1400 1277 1330 1771 1293 1716
