126
RT-SVX24Q-EN
Table 52. Energy recovery wheel component static pressure drops — air-cooled and evaporative condensing —
standard CFM (continued)
Nom Tons
AC/EC
CFM
Outside Air
Bypass
Damper Open
Outside Air
Bypass
Damper Closed
Exhaust Air
Bypass
Damper Open
Exhaust Air
Bypass
Damper Closed
Standard CFM Energy Recovery Wheel
120/128
10000 0.10 0.56 0.11 0.50
12000 0.14 0.69 0.16 0.63
15000 0.20 0.89 0.23 0.85
18000 0.27 1.10 0.29 1.05
21000 0.35 1.33 0.38 1.28
24000 0.43 1.57 0.47 1.51
26000 0.50 - 0.54 -
31000 0.66 - 0.72 -
36000 0.84 - 0.91 -
41000 1.04 - 1.11 -
46000 1.26 - 1.34 -
51000 1.49 - 1.56 -
54000 1.63 - 1.71 -
130-162
13000 0.16 0.59 0.17 0.53
15000 0.20 0.69 0.22 0.63
18000 0.26 0.86 0.28 0.79
21000 0.33 1.04 0.36 0.96
23000 0.38 1.16 0.42 1.06
26000 0.45 1.36 0.50 1.24
29000 0.54 1.57 0.60 1.42
30000 0.57 - 0.63 -
35000 0.72 - 0.80 -
40000 0.89 - 0.98 -
45000 1.08 - 1.17 -
50000 1.28 - 1.38 -
55000 1.50 - 1.60 -
58000 1.63 - 1.74 -
Table 53. Energy recovery wheel component static pressure drops — air-cooled and evaporative condensing —
dampers
Tons AC/EC
CFM
Return Damper,
ERW only
Econo Damper,
ERW only
90/100
16000 0.14 0.15
20000 0.2 0.24
25000 0.29 0.39
30000 0.42 0.56
33000 0.51 0.69
36000 0.61 0.82
40000 0.75 1.01
105/118
19000 0.19 0.22
23000 0.25 0.33
28000 0.37 0.49
33000 0.51 0.69
38000 0.68 0.91
43000 0.87 1.17
45000 0.96 1.29
UUnniitt SSttaarrttuupp
