164
RT-SVX24Q-EN
Table 57. Standard units with ERW — field measured plenum pressure — Standard CFM ERW — 90-162 Tons (continued)
51000 2.47 2.39 2.24 2.01 1.7 1.39
54000 2.74 2.65 2.48 2.22 1.87 1.52
130-162 Ton Standard CFM ERW - Field measured plenum pressure (inches wc)
CFM
OA Actuator Reading [Degrees] RA Actuator Reading [Degrees]
60 50 40 30 20 10 0 10 20 30 35 40 45
Econ
Traq
Econ
Traq
Econ
Traq
Econ
Traq
Econ
Traq
Econ
Traq
E/T E/T E/T E/T E/T E/T E/T
23000 1.73 1.18 1.92 0.97 1.18 0.87 0.96 0.82 0.93 0.8 0.78 0.58 0.56 0.53 0.48 0.42 0.35 0.3
26000 2.19 1.49 2.43 1.22 1.48 1.09 1.2 1.03 1.16 1 0.97 0.71 0.69 0.65 0.59 0.51 0.43 0.35
30000 2.89 1.95 1.59 1.94 1.42 1.56 1.34 1.52 1.29 1.26 0.91 0.88 0.83 0.75 0.64 0.54 0.44
35000 2.59 2.11 2.58 1.88 2.07 1.76 2.01 1.71 1.66 1.19 1.15 1.08 0.97 0.82 0.67
40000 2.71 2.41 2.66 2.26 2.57 2.18 2.12 1.5 1.45 1.36 1.22 1.02 0.83
45000 3 2.8 2.71 2.63 1.84 1.78 1.66 1.49 1.24 1
50000 2.23 2.15 2.01 1.79 1.49 1.19
55000 2.65 2.55 2.38 2.11 1.75
58000 2.91 2.8 2.61 2.31 1.91
Energy Recovery Wheel (ERW)
The IntelliPak™ 2 energy wheel section consists of the
energy wheel cassette assembly, return air, outside air,
and bypass dampers, and outside air mist eliminators.
Double opposing large access doors are provided on
both sides of the section for service access into the
return/exhaust air compartment, see “Figure 125,” p.
160.
UUnniitt SSttaarrttuupp
