Table 51. Energy recovery wheel component static pressure drops — air-cooled and evaporative condensing — low
CFM (continued)
Nom Tons
AC/EC
CFM
Outside Air
Bypass
Damper Open
Outside Air
Bypass
Damper Closed
Exhaust Air
Bypass
Damper Open
Exhaust Air
Bypass
Damper Closed
Low CFM Energy Recovery Wheel
150/162
9000 0.09 0.71 0.10 0.62
12000 0.15 0.97 0.18 0.92
16000 0.25 1.34 0.28 1.33
20000 0.36 — 0.40 —
23000 0.46 — 0.49 —
26000 0.57 — 0.60 —
30000 0.72 — 0.75 —
35000 0.93 — 0.97 —
40000 1.16 — 1.20 —
45000 1.40 — 1.43 —
50000 1.67 — 1.69 —
55000 1.95 — 1.96 —
58000 2.12 — 2.12 —
Table 52. Energy recovery wheel component static pressure drops — air-cooled and evaporative condensing —
standard CFM
Nom Tons
AC/EC
CFM
Outside Air
Bypass
Damper Open
Outside Air
Bypass
Damper Closed
Exhaust Air
Bypass
Damper Open
Exhaust Air
Bypass
Damper Closed
Standard CFM Energy Recovery Wheel
90/100
8000 0.06 0.54 0.07 0.44
9000 0.08 0.61 0.10 0.53
10000 0.10 0.68 0.12 0.62
12000 0.15 0.83 0.17 0.77
14000 0.19 0.99 0.22 0.94
16000 0.24 1.16 0.26 1.12
18000 0.30 1.32 0.31 1.29
20000 0.35 - 0.37 -
25000 0.52 - 0.54 -
30000 0.70 - 0.73 -
33000 0.82 - 0.84 -
36000 0.95 - 0.97 -
40000 1.12 - 1.14 -
105/118
9000 0.08 0.57 0.09 0.47
12000 0.14 0.77 0.16 0.65
14000 0.19 0.93 0.21 0.78
16000 0.24 1.08 0.26 0.91
19000 0.32 1.33 0.34 1.11
21000 0.37 1.49 0.40 1.25
23000 0.44 - 0.46 -
28000 0.61 - 0.64 -
33000 0.80 - 0.82 -
38000 1.00 - 1.03 -
43000 1.23 - 1.25 -
45000 1.33 - 1.34 -
