Table 51. Energy recovery wheel component static pressure drops — air-cooled and evaporative condensing — low

CFM

Nom Tons

AC/EC

CFM

Outside Air

Bypass

Damper Open

Outside Air

Bypass

Damper Closed

Exhaust Air

Bypass

Damper Open

Exhaust Air

Bypass

Damper Closed

Low CFM Energy Recovery Wheel

90/100

8000 0.07 0.78 0.09 0.66

9000 0.09 0.88 0.11 0.79

10000 0.12 0.99 0.14 0.92

12000 0.16 1.20 0.19 1.16

14000 0.21 1.42 0.24 1.41

16000 0.27 — 0.29 —

20000 0.40 — 0.42 —

25000 0.59 — 0.60 —

30000 0.80 — 0.80 —

33000 0.94 — 0.94 —

36000 1.08 — 1.07 —

40000 1.30 — 1.27 —

105/118

9000 0.09 0.88 0.11 0.79

12000 0.16 1.20 0.19 1.16

14000 0.21 1.42 0.24 1.41

16000 0.27 — 0.29 —

19000 0.36 — 0.39 —

23000 0.51 — 0.52 —

28000 0.71 — 0.72 —

33000 0.94 — 0.94 —

38000 1.19 — 1.18 —

43000 1.46 — 1.41 —

45000 1.58 — 1.52 —

120/128

9000 0.09 0.78 0.11 0.69

12000 0.16 1.06 0.18 1.02

15000 0.23 1.36 0.26 1.36

18000 0.31 — 0.34 —

21000 0.41 — 0.44 —

26000 0.59 — 0.62 —

31000 0.79 — 0.82 —

36000 1.01 — 1.04 —

41000 1.25 — 1.28 —

46000 1.51 — 1.52 —

51000 1.79 — 1.79 —

54000 1.96 — 1.95 —

130/140

9000 0.09 0.71 0.10 0.62

12000 0.15 0.97 0.18 0.92

16000 0.25 1.34 0.28 1.33

20000 0.36 — 0.40 —

23000 0.46 — 0.49 —

26000 0.57 — 0.60 —

30000 0.72 — 0.75 —

35000 0.93 — 0.97 —

40000 1.16 — 1.20 —

45000 1.40 — 1.43 —

50000 1.67 — 1.69 —

55000 1.95 — 1.96 —

58000 2.12 — 2.12 —
