Table 61. eFlex™ staging sequence and compressor data
90 Ton eFlex™ Variable Speed Compressor
Stage
1A CSHN184 1B CSHN184 1C CSHN184 2A VZH170 2B CSHN184
VZH min
Speed
VZH max
Speed
1 X 2400 5280
2 X X 1500 5460
3 X X X 2040 5100
4 X X X X 1500 6000
5 X X X X X 2040 5000
105 Ton eFlex™ Variable Speed Compressor
Stage
1A CSHN184 1B CSHN184 1C CSHN184 2A VZH170 2B CSHN250
VZH min
Speed
VZH max
Speed
1 X 2640 5220
2 X X 1500 5460
3 X X X 2040 5600
4 X X X X 1500 6000
5 X X X X X 1500 6000
120 Ton eFlex™ Variable Speed Compressor
Stage
1A CSHN184 1B CSHN184 1C CSHN250 2AVZH170 2B CSHN315
VZH min
Speed
VZH max
Speed
1 X 3000 5280
2 X X 1500 5520
3 X X X 2100 5000
4 X X X 2700 6000
5 X X X X 1500 6000
6 X X X X X 1500 6000
130 Ton eFlex™ Variable Speed Compressor
Stage
1A CSHN184 1B CSHN184 1C CSHN315 2A VZH170 2B CSHN374
VZH min
Speed
VZH max
Speed
1 X 3300 5640
2 X X 1740 5340
3 X X X 1860 5000
4 X X X 1500 6000
5 X X X X 1500 5700
6 X X X X 1500 6000
