RT-SVX24Q-EN
19
Figure 9. Unit component layout and “ship with” locations
Re turn/
Exhaus t
Fan
Outside
Air
Dampe rs
Supply Fan
Condens er
Fans
Compress or
Section
Hea ting
S
ec
t
io
n
Exhaust Damp er
Hood
Evap Coi l
Evap Coi l
Con trols
Variable
Frquency
Drive (VF D)
Filter Section
Rehea t Coil Option
Outside Air
Dampe rs
Re turn Air Dampe rs
Flue Vent
Access
Variable
Frquency
Drive (VF D)
Hot Water/Steam
Hydronic Conne ction
Outside Air
St
atic Kit and
sensors
Figure 10. Space temperature averaging with
multiple sensors
Single Zone Aver
aging Circuit
Four Zone Averaging Circuit
Nine Zone Averaging Circuit
Remote Sensor #1
Remote Sensor #1
Remote Sensor #1
Remote Sensor #4
Remote Sensor #4
Remote Sensor #5 Remote Sensor #6
Remote Sensor #7 Re
mote Sensor #8 Remote Sensor #9
Remote Sensor #2
Remote Sensor #2
To Terminals
on the Zone Sensor
Module or to 1TB4
To Terminals
on the Zone Sensor
Module or to 1TB4
To Terminals
on the Zone Sensor
Module or to 1TB4
Remote Sensor #3
Unit Control Modules
Unit control modules are microelectronic circuit boards
designed to perform specific unit functions. The control
modules, through proportional/integral control
algorithms, provide the best possible comfort level for
the customer. They are mounted in the control panel
and are factory wired to their respective internal
components.
The control modules receive and interpret information
from other unit modules, sensors, remote panels, and
customer binary contacts to satisfy the applicable
request for economizing, mechanical cooling, heating,
and ventilation. The figure below illustrates the typical
location of each designated module.
GGeenneerraall IInnffoorrmmaattiioonn
