Table 69. Compressor circuit breaker electrical characteristics
Unit Size
Compressor
Designator
Compressor
Size
460V 575V 380V
Must
Hold
Must
Trip
Must
Hold
Must
Trip
Must
Hold
Must
Trip
90/105
1A, 2A
CSHN250 41.5 47.7 33.2 38.2 41.4 47.6
1B, 2B
CSHN250 41.5 47.7 33.2 38.2 41.4 47.6
105/118
1A, 2A
CSHN250 41.5 47.7 33.2 38.2 41.4 47.6
1B, 2B
CSHN315 54.4 62.6 43.6 50.1 54.3 62.4
120/128
1A, 2A
CSHN315 57.7 66.4 46.3 53.2 57.3 66
1B, 2B
CSHN315 54.4 62.6 43.6 50.1 54.3 62.4
130/140
1A, 2A
CSHN315 57.7 66.4 46.3 53.2 57.3 66
1B, 2B
CSHN374 63.4 72.9 50.0 57.5 63.3 72.8
150/162
1A, 2A
CSHN374 66.7 76.7 52.7 60.6 66.4 76.3
1B, 2B
CSHN374 63.4 72.9 50.0 57.5 63.3 72.8
