RT-SVX24Q-EN
213
Table 82. Wiring diagram matrix (continued)
Air Cooled Water Cooled
Tonnage
Description
2309-3645
All Tonnages +
Air Handler
Schematic, LHI, ECEM, VCM, MPM w/o Exh or Rtn VFD
2309-3648
All Tonnages Schematic, LHI, ECEM, VCM, MPM 2-Pc, w/o Exh or Rtn VFD
2309-3649
All Tonnages Schematic, LHI, ECEM, VCM, MPM 2-Pc w/Return VFD
2309-3650
All Tonnages Schematic, LHI, ECEM, VCM, MPM 2-Pc w/Exhaust VFD
2309-3772
All Tonnages Schematic, LHI, ECEM, VCM, MPM 3-Pc, w/o Exh or Rtn VFD
2309-3773
All Tonnages Schematic, LHI, ECEM, VCM, MPM 3-Pc w/Return VFD
2309-3774
All Tonnages Schematic, LHI, ECEM, VCM, MPM 3-Pc w/Exhaust VFD
2313-0867
All Tonnages +
Air Handler
Schematic, VOM, LCI, IPCB, GBAS 0-5V,GBAS 0-10V, BCI, WCI
CV
Power
1-Piece 2313-0819 90-150T
Schematic, Power - Standard
2313-0831
90T, 105T Schematic, Power - Standard w/Low Ambient
2313-0843
120T,130T,150T Schematic, Power - Standard w/Low Ambient
2313-0855 100-162T
Evap Cooled Schematic, Power 2-Pc - Standard
2313-0863 Air Handler
Schematic, Power - Standard Air Handler
Multi-Piece 2313-0823 90-150T
Schematic, Power - Standard 2-Pc
2313-0827 90-150T
Schematic, Power 3-Pc - Standard
2313-0835
90T, 105T Schematic, Power 2-Pc - Standard w/Low Ambient
2313-0839
90T, 105T Schematic, Power 3-Pc - Standard w/Low Ambient
2313-0847
120T,130T,150T Schematic, Power 2-Pc - Standard w/Low Ambient
2313-0851
120T,130T,150T Schematic, Power 3-Pc - Standard w/Low Ambient
2313-0859 100-162T
Schematic, Power 3-Pc - Standard
Controls
1-Piece 2309-3652
All Tonnages +
Air Handler
Notes and Specs
2313-0817
All Tonnages +
Air Handler
Field Connection CV
2313-0868 90-150T
Connection, Control Box - Standard
2313-0876 90-105T
Connection, Control Box - Standard w/Low Ambient
2313-0884 120-150T
Connection, Control Box - Standard w/Low Ambient
2313-0896 Air Handler
Connection, Control Box - Standard Air Handler
2313-0900
90-150T & Air
Handler
Connection, Common Control Modules - w/o Return VFD
2313-0901 100-162T
Connection, Common Control Modules - w/o Return VFD
2309-3787 90-150T
Connection, Raceway Devices - Condenser Zone (Air Cooled)
2313-0816 100-162T
Connection, Raceway Devices - Condenser Zone (Evap Cooled)
2309-3789 Air Handler
Connection, Raceway Devices - Condenser Zone (Air Handler)
2309-3740 Air Handler
Connection, Raceway Devices - Air Handler Standard
Multi-Piece 2309-3756 90-162 Ton
Connection, Raceway Devices - Standard Evap Module
2309-3685
All Tonnages +
Air Handler
Schematic, Controls - Cooling Only
2309-3652
All Tonnages +
Air Handler
Notes and Specs
2313-0900
90-150T & Air
Handler
Connection, Common Control Modules - w/o Return VFD
2313-0817
All Tonnages +
Air Handler
Field Connection CV
2313-0872 90-150T
Connection, Control Box - Standard 2/3-Pc
2313-0880 90-105T
Connection, Control Box - Standard w/Low Ambient 2/3-Pc
2313-0888 120-150T
Connection, Control Box - Standard w/Low Ambient 2/3-Pc
2313-0892 100-162T
Connection, Control Box - Standard 2/3-Pc
2313-0900 90-150T & AH
Connection, Common Control Modules - w/o Return VFD
2313-0901 100-162T
Connection, Common Control Modules - w/o Return VFD
2309-3787 90-150T
Connection, Raceway Devices - Condenser Zone (Air Cooled)
2313-0816 100-162T
Connection, Raceway Devices - Condenser Zone (Evap Cooled)
2309-3789 Air Handler
Connection, Raceway Devices - Condenser Zone (Air Handler)
2309-3724 90-162 Ton
Connection, Raceway Devices - Evap Module Standard 3-Pc
2309-3725 90-162 Ton
Connection, Raceway Devices - Evap Module w/Supply VFD 3-Pc
2309-3726 90-162 Ton
Connection, Raceway Devices - Evap Module w/Exh/Rtn VFD 3-Pc
2309-3727 90-162 Ton
Connection, Raceway Devices - Evap Module w/Sup & Exh/Rtn VFD 3-Pc
UUnniitt WWiirriinngg DDiiaaggrraamm NNuummbbeerrss
