Table 17. Downflow/horizontal airflow configuration dimensions (in.) air-cooled (AC) and evaporative condensing
(EC) with energy recovery wheel
Tonnage
AC/EC
Blank
Section
Gas
Heat
DOWNFLOW Opening Dimensions
Return Opening-with or without
Exhaust Fan
Return
Opening-with
Return Fan
Supply Opening
X1 Y1 W1 L1 X1 Y1 W1 L1
X2 (One
or Two-
Piece
Models)
X2
(Three-
Piece
Models)
Y2 W2 L2
90-105/
100-118
None None
82 3/16 8 14/16 49 10/16 121 15/16 N/A N/A N/A N/A 352 8/16 371 12/16
13
47 14/16 102 8/16
4 ft None
82 3/16 8 14/16 49 10/16 121 15/16 N/A N/A N/A N/A
400 11/
16
420 13
47 14/16 102 8/16
8 ft None
82 3/16 8 14/16 49 10/16 121 15/16 N/A N/A N/A N/A
448 15/
16
468 3/16
13
47 14/16 102 8/16
120-150/
128-162
None None
82 3/16 8 14/16 49 10/16 121 15/16 N/A N/A N/A N/A 417 4/16 442 11/16
13
47 14/16 102 8/16
4 ft None
82 3/16 8 14/16 49 10/16 121 15/16 N/A N/A N/A N/A 465 7/16 490 14/16
13
47 14/16 102 8/16
8 ft None
82 3/16 8 14/16 49 10/16 121 15/16 N/A N/A N/A N/A
513 10/
16
539 2/16
13
47 14/16 102 8/16
90-105/
100-118
None
Low/Med 82 3/16 8 14/16 49 10/16 121 15/16 N/A N/A N/A N/A 352 8/16 371 12/16
13
47 14/16 102 8/16
8 ft
Low/Med 82 3/16 8 14/16 49 10/16 121 15/16 N/A N/A N/A N/A
448 15/
16
468 3/16
13
47 14/16 102 8/16
120-150/
128-162
None
Low/Med 82 3/16 8 14/16 49 10/16 121 15/16 N/A N/A N/A N/A 417 4/16 442 11/16
13
47 14/16 102 8/16
8 ft
Low/Med 82 3/16 8 14/16 49 10/16 121 15/16 N/A N/A N/A N/A
513 10/
16
539 2/16
13
47 14/16 102 8/16
None
High
82 3/16 8 14/16 49 10/16 121 15/16 N/A N/A N/A N/A 417 4/16 442 11/16
13
59 14/16 102 8/16
Tonnage
AC/EC
Blank
Section
Gas
Heat
HORIZONTAL Opening Dimensions
Return Side Opening Supply Opening
X3 Y3 W3 H1
X4 (One
or Two-
Piece
Models)
X4
(Three
Piece
Models)
Y4 W4 H2
90-105/
100-118
None None
71 8/16 10 10/16 54 12/16 43 6/16 351 3/16 370 7/16 10 10/16 54 12/16 84 15/16
4 ft None
71 8/16 10 10/16 54 12/16 43 6/16 399 6/16 418 11/16 10 10/16 54 12/16 84 15/16
8 ft None
71 8/16 10 10/16 54 12/16 43 6/16 447 10/16 466 14/16 10 10/16 54 12/16 84 15/16
120-150/
128-162
None None
71 8/16 10 10/16 54 12/16 43 6/16 415 15/16 441 6/16 10 10/16 54 12/16 84 15/16
4 ft None
71 8/16 10 10/16 54 12/16 43 6/16 464 2/16 489 10/16 10 10/16 54 12/16 84 15/16
8 ft None
71 8/16 10 10/16 54 12/16 43 6/16 512 6/16 537 13/16 10 10/16 54 12/16 84 15/16
90-105/
100-118
None
Low/Med 71 8/16 10 10/16 54 12/16 43 6/16 351 3/16 370 7/16 10 10/16 54 12/16 66 11/16
8 ft
Low/Med 71 8/16 10 10/16 54 12/16 43 6/16 447 10/16 466 14/16 10 10/16 54 12/16 84 15/16
120-150/
128-162
None
Low/Med 71 8/16 10 10/16 54 12/16 43 6/16 415 15/16 441 6/16 10 10/16 54 12/16 66 11/16
8 ft
Low/Med 71 8/16 10 10/16 54 12/16 43 6/16 512 6/16 537 13/16 10 10/16 54 12/16 84 15/16
None
High
71 8/16 10 10/16 54 12/16 43 6/16 415 15/16 441 6/16 10 10/16 66 12/16 66 11/16
Notes:
1. On horizontal return with ERW units, the return end opening can be on the front, rear, or both sides of the unit and must be
specified.
2. ERW is not allowed w/ end return
