RT-SVX24Q-EN
79
Table 39. Electrical service sizing data—energy
recovery wheel motor — air-cooled and
evaporative condensing
Nom Tons AC/EC
Unit Function
Voltage
460 575
FLA FLA
90-120/100-128
1 (Low CFM ERW)
1.2 0.95
130-150/140-162
1 (Low CFM ERW)
1.7 1.4
All
2 (Std. CFM ERW)
1.7 1.4
Table 40. Electrical service sizing data—evaporative
condenser
Unit Part kW
hp
Voltage
460
FLA
Pump 1.5 2.7
Sump Heater 3 3.8
