INSTRUCTION MANUAL
UG30 CONTROL
mP30-UG30 - Rev. 1.5 - Date: 18-03-2004 EN
31 (44)
REMOTE CONTROL OF UNIT
The unit can be started and stopped alternatively by :
1. a remote contact (or “remote control”);
2. a “supervision system” connected to the microprocessor by a serial cable.
ON/OFF FROM REMOTE CONTACT: the unit is started via the ID1 digital input. When the input is open, the unit is
on stand-by signalled by the “OFF” symbol on the display. If, instead, 24V is supplied, the unit is powered up
(signalled by the “ON” symbol on the display).
GLb GENERAL
Minimum Maximum
Default
HE
ON/OFF digital input: enables the ID1 digital input as a remote ON/OFF.
0= absent
1= present, disables ON/OFF switching from the keyboard.
2= absent, disables ON/OFF switching from the keyboard (only in the case
of supervision systems)
0 2 0
SUPERVISION SYSTEM
A supervision system exchanges data via serial cable with the unit’s basic circuit which is remotely commanded and
controlled: to this end, the RS485 Serial Circuit (optional) must be present.
GLb GENERAL
Minimum Maximum
Default
Ho
Serial address in the RS485 supervision network. 1 200 1
HP
Supervisor serial Baudrate. It sets the line speed on the RS485 supervision
network.
1= 1200 Baud
2= 2400 Baud
3= 4800 Baud
4= 9600 Baud
5= 19200 Baud
1 5 5
