Trane mP30 User Manual

INSTRUCTION MANUAL
UG30 CONTROL
42 (44)
mP30-UG30 - Rev. 1.5 - Date: 18-03-2004 EN
DEFAULT VALUES
Prob SENSORS
Type Minimu
m
maximum Measurement
unit
Default
/1 Sensor B2 presence (external air temperature) FACTORY 0 1 flag 0,1
/2 Sensor B3 presence (room relative humidity) FACTORY 0 2 flag 0,2
/3 Sensor B4 presence (delivery temperature) FACTORY 0 1 flag 0,1
/4 Humidity value at 4mA FACTORY 0 /5 %R.H. 0.0
/5 Humidity value at 20mA FACTORY /4 100 %R.H. 100.0
/6 Sensor B1 calibration (room temperature) FACTORY -6.0 6.0 °C 0
/7 Sensor B2 calibration (external air temperature) FACTORY -6.0 6.0 °C 0
/8 Sensor B3 calibration (room relative humidity) FACTORY -10 10 %R.H. 0
/9 Sensor B4 calibration (delivery temperature) FACTORY -6.0 6.0 °C 0
/C Measurement unit (0=C,1=F) USER 0 1 flag 0
SEtP REGULATOR
Type Minimu
m
maximum Measurement
unit
Default
r1 Temperature (summer) set-point. USER rA rb °C 23
r2 Cooling differential. USER 0.1 11.0 °C 1.5
r3 Heating differential. USER 0.1 11.0 °C 1.5
r4 Temperature neutral zone. USER 0.1 20.0 °C 0.2
r5 Humidity set-point USER rC rd %R.H 50
r6 Humidification differential USER 1 20 %R.H. 5
r7 Dehumidification differential USER 1 20 %R.H. 5
r8 Humidity neutral zone. USER 0 20 %R.H. 10
rA Minimum temperature set point FACTORY -20 rb °C 0.0
rb Maximum temperature set point FACTORY rA 60 °C 35.0
rC Minimum humidity set point FACTORY 0 rd %R.H. 20
rd Maximum humidity set point FACTORY rC 100 %R.H. 90
rE Adjustment type FACTORY 0 1 flag 1
rF Integration time for P+I FACTORY 10 3600 sec 600
rG Enable compensation FACTORY -2.0 2.0 - 0.0
rn Minimum delivery temperature set point FACTORY -20 30 °C 15
Com COMPRESSOR
Type Minimu
m
maximum Measurement
unit
Default
c4 Delayed start-up between two compressors FACTORY 0 300 sec 90 (DX-DX/S)
c6 Compressor rotation FACTORY 0 1 flag 1 (DX-DX/S)
c7 Delayed compressor start from fan start-up. FACTORY 0 300 sec 60 (DX-DX/S)
c8 Hour-counter threshold for compressor (0=disabled hour-counter) USER 0 30000 hours 0 (DX-DX/S)
c9 Compressor 1 hour-counter USER 0 30000 hours 0 (DX-DX/S)
cA Compressor 2 hour-counter USER 0 30000 hours 0 (DX-DX/S)
FAn FANS
Type Minimu
m
maximum Measurement
unit
Default
F1 Fan mode functioning FACTORY 0 1 flags 0= no RV
1= con RV
F9 Hour-counter threshold for fan (0=disabled hour-counter) USER 0 30000 hours 0
FA Delivery fan hour-counter USER 0 30000 hours 0
Fb Hour-counter threshold for filter (0=disabled hour-counter) USER 0 30000 hours 1000
Fc Filter hour-counter USER 0 30000 hours 0
Fd Fan delayed switch-off FACTORY 0 900 sec 10
ALAR ALARM
Type Minimu
m
maximum Measurement
unit
Default
P1 Delayed flow alarm at start FACTORY 0 250 sec 30
P2 Delayed flow alarm during operation FACTORY 0 90 sec 3
P3 Delayed low pressure alarm at compressor start-up FACTORY 0 500 sec 180
(DX-DX/S)
P4 Buzzer activation USER 0 15 min 1
P5 Reset alarms FACTORY 1 5 flag 3
P6 Delta from set for low temperature alarm FACTORY 0 50 °C 13.0
P7 Delta from set for high temperature alarm FACTORY 0 50 °C 7.0
P8 Delta from set for low humidity alarm FACTORY 0 50 %R.H. 20.0
P9 Delta from set high humidity alarm FACTORY 0 50 %R.H. 30.0
PA Alarm start delay high/low temperature /humidity USER 0 150 min 15
Pb Management type general alarm input ID5 FACTORY 0 6 flag 2
PC General alarm delay USER 0 250 sec 0
