TNX65/42
General data
Ambient conditions
Refer to the chapter Ambient conditions in the Safety instructions.
Please contact machine manufacturer or a machine manufacturer's
agent if conditions at the installation site diverge from those
specified.
Substrate, foundations
The load capacity and strength of the flooring must be sufficient to bear the
weight of the machine in structural terms.
Expansion joints are not permitted in the area under the machine.
Bar feeding and re-feeding mechanisms, as well as bar loading magazines must
be anchored in the foundations as a matter of principle (for further details refer
to the associated User manual and Installation drawing).
Bottom sump
If a bottom sump is required, it must be as in the "Information on
bottom sump drawing" specifications so that extending out of the
relevant chip conveyor is guaranteed as required.
The base in the area of the bottom sump may only be convex by a maximum of
5 mm (and be flat or concave if possible). If the permitted unevenness is
exceeded, the bottom sump may rub against the underside of the machine /
machine components.
Compressed air supply
See chapter Pneumatic connection
Equipment to be provided
See chapter Fuels and Notes on Operating Materials
Pumps and tanks
A simple pump will suffice to extract the spent lubricoolant. The same pump
can also be used to fill the lubricoolant tank, but must first be thoroughly rinsed
with fresh lubricoolant.
A sturdy container is needed to collect the extracted fluids. Tightly closing and
duly labelled metal containers of corresponding capacity can be used for this
purpose.
