33
10.2016
TNX65/42
Transporting the machine
Transport by fork lift truck
Requirements to be met by a fork lift truck
Min. lifting capacity kg 12000
Min. fork length mm 2200
Load centre mm 1200
The fork lift truck must have a minimum load capacity of 12 t. The
machine may only be lifted from the operator side. When setting
down the machine, ensure that the fork arms are not inclined,
otherwise the planks may break.
To prevent damage to the machine, the rear wheel must be
removed from the control cabinet before transporting it.
