TNX65/42
Alignment, component installation and commissioning
Precise alignment of the machine
Requirements
• The hydraulic unit in the fluid cabinet must be filled with hydraulic fluid.
• The machine must be connected to the power supply.
Switching on the machine
Before the machine is put into operation for the first time, its
owner must ensure that the machine and its safety mechanisms are
in good working order. This must also be checked at reasonable,
regular intervals during operation, but at least whenever the
machine has been repaired or serviced.
• Switch on the machine at the master switch.
• Press "NC ON".
• Press "Drives ON".
• Open/close working area door (activate safety function).
Check / correct position and torsion of the machine
Precision adjustment of the machine is carried out with the aid of a fixture
inserted in the turret on tool carrier 2.
Spirit levels with an accuracy of 0.02 mm/m are placed on this fixture in Z and X
directions in order to check the machine’s position and torsion.
