47
10.2016
TNX65/42
Installation of the milling unit components
Openings for fitting the
connecting pins of the chain
links
Connect the chain of the chain magazine (only with optional 120
positions)
Risk of injury!
The tool chain must be secured at the separating points by
suitable means so it cannot fall down.
Two openings are provided in the tool magazine for fitting the connecting pins
of the chain links.
