48
10.2016
TNX65/42
Installation of the milling unit components
• Lift the ends of the chain with suitable means, move them into position to
connect the chain links and secure them so they cannot fall down.
• Push through the connecting pin with bearing and fit the bearing on the
opposite side.
• Attach the circlip to the connecting pin.
Connecting pin
2. Insert bearing
1. Push through connecting
pin with bearing
3. Attach circlip
