TREPEL CHALLENGER550 - Rocker Switch, Steering Program

Page 39
1-2
General Information and Operating Instructions
PUSHBACK TRACTOR CHALLENGER550
Jan 28/19
Figure 21: Rocker switch, steering program
The steering program is set using the toggle switch on the center console.
Table 5: Rocker switch, steering program
1
2 3 4
Pos. Pictogram Designation Description
1 Switch
"Front-wheel steering"
Select front-wheel steering. 
The selection is indicated in the display.
2 Switch
"Rear-wheel steering"
Select rear-wheel steering. 
The selection is indicated in the display.
3 Switch
"Diagonal steering"
Select diagonal steering. 
The selection is indicated in the display.
4 Switch
"Four-wheel steering"
Select four-wheel steering. 
The selection is indicated in the display.
