Page 7
1-2
General Information and Operating Instructions
PUSHBACK TRACTOR CHALLENGER550
Jan 28/19
Engine oil level
(1) Check the engine oil level on the oil dip stick 2.
Figure 2: Oil dip stick
1 Maintenance opening
2 Oil dip stick
Engine damage!
If the oil level is too high or too low, this can result in damage to the engine.
Make sure that the oil level is never above the "MAX" marking and never below the "MIN"
marking.
Use only authorized types of oil.
(2) Pull the oil dip stick.
(3) Wipe the oil dip stick with a clean, lint-free cloth.
(4) Reinsert the oil dip stick completely.
(5) Pull the oil dip stick out again.
(6) Hold the oil dip stick vertically downwards.
(7) Check if the oil level is between the "MIN" and "MAX" marking.
1
2
