F. Driver workplace
Figure 24: Driver workplace CHALLENGER550
1 Hazard lights
2 "Group fault" control light and warning buzzer
3 Analog displays
4 Rocker switch / Toggle switch
5 Preheater starter switch
6 Display
7 Battery charge indicator
8 Rocker switch "Diesel pre-heating"
9 Heater/Ventilation
10 Gear selector lever
11 Rocker switch for setting the suspension and cab
12 Parking brake
13 Rocker switch, steering program
14 Pedals
14
98
12
3
45
10
6
12
13 11
7
