TREPEL CHALLENGER550 - Display; Reception Screen - Display; Display Overview

Page 55
1-1
General Information and Operating Instructions
PUSHBACK TRACTOR CHALLENGER550
Jan 28/19
Display
Figure 27: Reception screen - display
Figure 28: Display overview
1 Display area "1" top
2 Display area "2" middle
3 Display area "3" bottom
