TREPEL CHALLENGER550 - Danger Area; Danger Area of the CHALLENGER550

Page 7
1-1
General Information and Operating Instructions
PUSHBACK TRACTOR CHALLENGER550
Jan 28/19
E. Danger area
To ensure safe operation no persons other than the operator are permitted to be in the danger area
of the CHALLENGER550. There is risk of injury or even death in the danger area.
Excluding the tow bar, no other objects may be located in the danger area of the CHALLENGER550
during operation.
The following diagram shows the danger area of the CHALLENGER550 and the clearances required
for safe operation of the CHALLENGER550.
Figure 2: Danger area of the CHALLENGER550
500 mm (1 ¾ ft)
500 mm (1 ¾ ft)
500 mm (1 ¾ ft) 500 mm (1 ¾ ft)
