TRIMOS V6 User Manual

User's Manual
750 50 0045 03 36
Air cushion adjustment (V4 ÷ V8)
The air flow of the pump can be adjusted according to the
quality of the work table with the help of the keys opposite.
Probing filter
Probing sensitivity can be adjusted, depending on the type
of insert used :
- SHORT: For short and stiff inserts (best accuracy)
- MEDIUM: For medium long and slightly rigid inserts
- LONG: For long and less rigid inserts
Note:
Probing filters "MEDIUM" and "LONG" reduce the probing
robustness. Precision and repeatability can differ from
specifications according to the user.
SmartReverse
The
SmartReverse
function facilitates the measurement of
diameters. By activating this function, the user is warned by
a specific audible signal and a blinking of the measured
values that the reversal point has been reached.
- SMART: SmartReverse mode enabled
- STANDARD: SmartReverse mode disabled
Sending data in diameter and centerline mode
It is possible to configure the sending of data of diameter
and centerline measurement modes (§5.3 and §6.3).
- BOTH: Simultaneous sending of diameter /
distance and center distance
- DIAMETER: Sending diameter / distance only
- CENTER: Sending the center distance only
- ALTERN: Sends the diameter / distance at the first
press of Print button and the center
distance at the second press.
Data transfer mode
The transfer of measured values can be configured
according to 2 modes :
- MANUAL: The transfer of the measured value is simply
carried out by pressing the data transfer
button.
- AUTO: The measured value is automatically
transferred after each probing.
Press opposite button to select requested mode.
