Setting Real Date, Time, Baud Rate and Unit Address for RS485 Port
In the above Programming Mode, press key till the unit enters into the following
display and then, set such as steps before.
Real Date and Time (RTC)
The Real Date can be set with the format of date, month and year (i.e.
DD/MM/YYYY). To set the Date, press key that will start blinking both “DD” and
Arrow. Set ‘DD’ by pressing and keys and then, press key to shift onto
month (MM) and set by pressing and keys as steps before. Likewise, set
years YYYY also.
The Real Time can also be as above steps with current time where the Time shows
with the format of hour, Minute and Second (i.e., HH/MM/SS). Here the Hour should
be set as 24 hour. This real time will also reflect into data logging which can be
observed after downloading logged data.
Baud Rate and Unit Address for RS485 Communication port.
In case of RS485 port, the BAUD RATE is settable to either 9600 or 19200 and the
unit Address is settable from 1 to 255.
Selecting Relays, Alarm Parameters, Alarm Values and Hysteresis
In the above Programming Mode, press key till the unit enters into the following
display and then, set such as steps before.
Relay (rly)
GOBLIN has four relay contacts, which are individually field programmable from 1 to
4.
Alarm on
There are seven alarm parameters: Avg. Volts [(Vry+Vyb+Vbr)/3], Avg. Amps
[(Ir+Iy+Ib)/3], KVA, KW, KVAR, KW Demand, KVA Demand and PF. These
>RELAY:1
ALARM ON:KVAR
ALARM VAL:1
R_HYSTER.:1 P
>DATE:28/02/2011
TIME:13:38:24
BAUD RATE:9600
ADDRESS:3 P
To Next Page
