Goblin – Operational Manual
TRINITY
[17]
which the event will log. E.g. If the EVENT ON for EVENT 1 has been selected to
KW, and the value is set to 450, the EVENT 1 will log when the KW exceeds 450
and remains so for 1 minute.
In case of PF, the PF value is entered with a multiplication factor of 1000. e.g. PF,
955 should be read as 0.955 with a multiplication factor of 1000. EVENT will thus
log when the PF falls below 0.955 and remains so for more than one minute.
Event Hysteresis
The Event Hysteresis is also same as Alarm Hysteresis defined before.
Selecting Demand Window (both KW and KVA), Installation type and
Reset Demand
In the above Programming Mode, press key till the unit enters into the following
display and then, set such as steps before.
Demand On
Demand Window specifies for both two Demands: KW and KVA and so the Demand
ON, KW & KVA are fixed that is not settable. For both the Demand Window, Sliding
and Fix Demand are an integration period of 30 or 15 minutes. The demand
calculation is selectable to Fix Demand or Sliding Demand with the following: FIX-15,
FIX-30, SLI-15 and SLI-30.
Installation type
The unit supports two types of Electrical installation such as 3P4W and 3P3W.
According to your electrical installation, the installation type should be selected to
either 3P4W or 3P3W as before setting.
Reset Demand
Reset Demand can be specified such as whether the demand will be reset
automatically or manually. In case of automatic reset, there are two options:
auto_day or auto_ month. If user selects auto_day then DEMAND will reset every 24
hrs at 12:00 a.m. and if user selects auto_month then DEMAND will reset on 1st of
every month at 7:00 a.m. Otherwise, RESET DEMAND should be set to MAN., to
reset manually.
DMN ON:KW & KVA
>DMD WIND:SLI_30
INST.:3P4W
RST DMD:MAN. P
