Goblin – Operational Manual
TRINITY
[38]
Appendix
Address Map of Various Parameters for 3P4W installation
Modbus
Address
Parameters Format MF
40200 Vln-R U-Long 100
40202 Vln-Y U-Long 100
40204 Vln-B U-Long 100
40206 Vln-Avg. U-Long 100
40208 Vll-RY U-Long 100
40210 Vll-YB U-Long 100
40212 Vll-BR U-Long 100
40214 Vll- Avg. U-Long 100
40216 Ir U-Long 100
40218 Iy U-Long 100
40220 Ib U-Long 100
40222 Iavg. U-Long 100
40224 I-neutral U-Long 100
40226 Future Use
40228 Future Use
40230 Hz U-Long 100
40232 System PF Long 1000
40234 PFr Long 1000
40236 PFy Long 1000
40238 PFb Long 1000
40240 System KW U-Long 100
40242 System KVAR Long 100
40244 S
y
stem KVA U-Lon
g
100
40246 KWr U-Long 100
40248 KWy U-Long 100
40250 KWb U-Long 100
40252 Kvar-r U-Long 100
40254 Kvar-y U-Long 100
40256 Kvar-b U-Lon
g
100
40258 Kva-r U-Lon
g
100
40260 Kva-y U-Long 100
40262 Kva-b U-Long 100
40264 KW demand U-Long 100
40266 MD-KW U-Long 100
40268 KVA=Demand U- Long 100
40270 MD-KVA U-Long 100
40272 Future Use
40274 Future Use
40276 Sys-KWh U-Long 100
40278 Sys-KVARh U-Long 100
40280 Sys.-KVARh-LG U-Long 100
40282 Sys.-KVARh-LD U-Long 100
40284 Sys-KVAh U-Long 100
40286 3rd Hvr U-Long 10
