TrojanTwo User Guide v3.8
Page | 17
Metric scale on magnet bar
6 Adjust position of label edge sensor to left edge of the label roll (see section 4.4 for adjusting label
edge sensor)
Label edge sensor in proper (default) position
Sensor Beam
99 mm
